This striking profile design offers a hand-split wooden shingle effect that brings elegant aesthetics to any rooftop.
The inspiration for the Metrotile Lightweight Roofing Viksen profile is to be found in the uniqueness of the ancient Viking architectural style. Used in building construction, their homes and other edifices were built entirely from wood, onto which small roof shingles were then applied extensively.
The hand-split wood pattern imparts an individual and rustic character to each building.
Metrotile Viksen is available in five standard colours. Viksen offers the same benefits from installation to our Forty Year Weatherproof Guarantee and can be installed to a minimum pitch of 15°. It is the ideal profile for those looking for an elegant, highly secure and rapidly installed roofing solution. For further information about Metrotile Lightweight Roofing, or a free no-obligation quotation, fill in our Online Contact Form Alternatively, call us from 9am to 5pm Mon-Fri on 01249 658 514.
Please note: Vixen requires longer lead time than our other profiles, so please remember this when planning. Contact us for further details.
Metrotile Viksen Roof Tile in Bronze
Fixings & Battens
| Tile Fixing: | 50 x 2.5mm Coated Nail. Hand nailing or power tool |
| Coated Nail: | Hand nailing or power tool |
| Fixings per tile: | 4 |
| Rafter Centres | Batten Size |
| Battens Required | 5 linear metres per m² (plus wastage) |
| 450mm | 25 x 50mm |
| 600mm | 25 x 50mm |
| 900mm | 50 x 50mm |
| 1200mm | 50 x 50mm |
| 1500mm | 50 x 65mm |
| Laying (recommended) | All roof shapes: broken bond |
Dimensions
| Pitch: | Minimum: 15° / Maximum: 90° |
| Dimensions : | Overall Size: 1325mm x 410mm |
| Cover Size : | 1260mm x 370mm |
| Gauge : | .410mm |
| Linear Cover Width : | 1257mm |
| Coverage : | 0.47m² / 2.15 per m² |
| Weight per m² : | 6.4Kg |
| Weight per tile: | 3.0Kg |
